Cage Type Industrial Lift

Get a Price/Quote

MOQ : 1 , , Unit

Cage Type Industrial Lift Specification

Type
Cage Type Industrial Lift

Voltage
380V / 415V AC

Hoist Way Size
As per site requirement

Pit Depth
150 mm to 300 mm

Usage
Warehouse, Factory, Material Handling

Inclination
Vertical movement only

Noise Level
<65 dB

Machine Room Size
Optional / As per installation

Door Opening Size
1000 mm x 2000 mm / As per requirement

Overhead Height
2000 mm (minimum)

Load Capacity
Up to 3 Tons

Car Dimension
2000 mm x 1500 mm x 2100 mm (customizable)

Material
MS/SS (Mild Steel/Stainless Steel)

Drive Type
Hydraulic / Electric

Power Supply
3 Phase, 50 Hz

Speed
0.15 to 0.5 m/s

Max. Lifting Height
20 m (customizable)

Max. Lifting Weight
3000 kg

Mechanism Type
Gear/Chain Driven

Working Temperature
-10C to +50C

Control Device
Push Button/PLC Control Panel

Safety Device
Emergency Stop, Overload Protection, Limit Switch

Capacity
500 kg to 3000 kg

Number of Stops
Customized (up to 8 stops)

Maintenance
Low maintenance requirements

Emergency Features
Emergency Alarm, Power Failure Lowering, Intercom (optional)

Door Type
Manual Swing/Fold/Automatic Sliding

Design Standard
As per EN/IS/ANSI Standards

Operation
Manual/Automatic (customized as per requirement)

Control Method
Call & Send Control/Interlocked Doors

Entry/Exit
Single/Double Side Entry

Customization
Size, finish, control system, and load capacity on request

Surface Finish
Powder Coating / Painted / Galvanized

Installation Type
Indoor / Outdoor

Power Consumption
2.2 kW to 7.5 kW, depending on load

Cage Type Industrial Lift Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
5 Units Per Month

Delivery Time
10 Days

About Cage Type Industrial Lift

Cage Type Industrial Lift

Our provided Cage Type Industrial Lift finds its application in various industries like textile, construction, electronics, cosmetic, furniture, packaging etc. Also, this lift is highly admired in shipyards, storage units, docks, retail stores, and harbors. It is used for vertical lifting and handling of various goods or materials. The offered lift ensures convenient transferring of loads from one level or floor to another. This Cage Type Industrial Lift is manufactured with the use of quality assured components and sophisticated techniques.

Key points:

High strength and excellent durability
Adjustable height due to I-Beam support
Limit switch to prevent over hoisting and lowering of hook

Robust and Customizable Design

The cage type industrial lift is tailored to fit individual requirements, with customizable size, number of stops (up to 8), power options, and finishes such as powder coating, painting, or galvanizing. Its sturdy construction allows efficient operation in diverse environments, ensuring reliable performance for a variety of material handling tasks.

Superior Safety and Easy Operation

Safety features include emergency alarm, overload protection, power failure lowering, and optional intercom. Door options range from manual swing to automatic sliding, all integrated with modern call & send control systems or interlocked doors for secure and user-friendly operation.

Flexible Installation and Low Maintenance

Suitable for both indoor and outdoor locations, the lift offers flexibility in installation with adjustable hoist way and machine room sizes. Its low-maintenance gear or chain-driven mechanism, combined with hydraulic or electric drive, ensures long-lasting use and minimal downtime, enhancing operational efficiency.

FAQs of Cage Type Industrial Lift:

Q: How is the cage type industrial lift installed and where can it be used?

A: The lift can be installed indoors or outdoors, with adaptable hoist way and pit requirements based on the installation site. It is employed in warehouses, factories, and material handling environments to efficiently transport goods between different levels.

Q: What customization options are available for this industrial lift?

A: Customization covers lift capacity (from 500 kg to 3000 kg), size, number of stops (up to 8), surface finish (powder coating, painting, or galvanizing), door type, control system, and lift dimensions, tailored per site and operational needs.

Q: When is maintenance required, and what does it involve?

A: The cage lift is designed for low maintenance. Routine checks, lubrication of moving parts, and periodic safety inspections are generally sufficient. The robust construction and quality materials help minimize major repairs or downtime.

Q: What are the operational benefits of using this lift?

A: This industrial lift streamlines material handling, increases workflow efficiency, and reduces manual transport risks. Its smooth hydraulic or electric drive, combined with customizable operation (manual or automatic), ensures reliable performance with low energy consumption.

Q: How does the lift ensure safety for operators and cargo?

A: Safety is prioritized with features like emergency stop, overload protection, limit switches, emergency alarm, power failure lowering, and optional intercom for communication. Interlocked doors and advanced control panels further secure daily operation.

Q: What process is involved in ordering and customizing a lift for specific requirements?

A: Customers can consult the manufacturer or supplier, specifying load capacity, dimensions, finish, control system, desired stops, and installation preferences. The product is then designed and manufactured as per the provided specifications, ensuring a precise fit for the application.
